grow light for 4x4 tent AC Infinity IONBOARD S44 | 430W Samsung LM301H LED Grow LightThe AC Infinity IONBOARD S44 is a high performance 430W LED grow light engineered to maximize yields in 4x4 grow tents. Utilizing high efficiency Samsung LM301H diodes, this board provides a sun like full spectrum that supports plants through every stage, from germination to flowering. Its algorithmically positioned diodes ensure uniform coverage and deep canopy penetration, while the unibody aluminum design allows for fanless, silent heat

The AC Infinity IONBOARD S44 is a high-performance 430W LED grow light engineered to maximize yields in 4x4 grow tents. Utilizing high-efficiency Samsung LM301H diodes, this board provides a sun-like full spectrum that supports plants through every stage, from germination to flowering. Its algorithmically positioned diodes ensure uniform coverage and deep canopy penetration, while the unibody aluminum design allows for fanless, silent heat dissipation.

Key Performance Highlights

• Samsung LM301H Diodes: Features 1024 top-tier LEDs for maximum light output and energy efficiency.

• Optimized Full Spectrum: Includes 660nm deep red and 730nm infrared to boost photosynthesis and flower density.

• Smart Ecosystem Ready: Connects to UIS™ controllers for automated grow cycles and mobile app management.

• Uniform PAR Distribution: Diode placement is scientifically mapped to prevent hot spots and ensure even growth across the canopy.

• Fanless Cooling: The unibody aluminum board acts as a massive heat sink, keeping the fixture cool without noisy fans.

• Precision Dimming: Includes an easy-to-use digital dimming knob with 20% increments for customized intensity.

• Durability & Safety: IP-65 rated against dust and moisture, and ETL certified for safe operation in grow environments.

Designed for the modern grower, the S44 features a proprietary driver with a digital dimming timer and UIS™ connectivity. This allows you to integrate the light into the AC Infinity smart ecosystem for remote app control and automated scheduling. With an IP-65 rating, the light is built to withstand the high humidity and temperatures common in indoor gardening, ensuring long-term reliability and peak performance.

Product Specifications

• Manufacturer: AC Infinity Inc.

• Model: IONBOARD S44 (AC-IBS44)

• UPC Code: 819137022546

• Form Factor: Ultra-slim unibody aluminum board (0.43 in. thickness) for silent, fanless cooling.

• Dimensions: 23.62 x 23.62 in. (60.0 x 60.0 cm).

• Coverage Area: Optimized for a 4 x 4 ft. grow space.

• Premium Diodes: Powered by 1,024 Samsung LM301H high-efficiency chips.

• Full Spectrum Output: Includes 660nm (Deep Red), 730nm (Infrared), 3000K, and 6500K to support all growth stages.

• Efficiency: High-output efficacy of 2.75 µmol/j.

• Peak Intensity: Exceptional light density reaching 2,034 PPFD.

• Wattage: 430W actual power draw.

• Driver: AC Infinity Proprietary Driver (IB-400).

• Voltage Compatibility: Multi-voltage 100–277V AC (50/60 Hz).

• Amperage: 3.60A @ 120V | 1.80A @ 240V | 1.56A @ 277V.

• Power Connection: US Plug (NEMA 1-15 Type-A).

• Smart Control: Equipped with a digital dimming timer and UIS™ connectivity for automated scheduling.

• Longevity: Commercial-grade life expectancy of 50,000 hours.

• Operating Conditions: Engineered for environments between 32–140°F and 35–85% RH.

• Safety Standards: ETL Certified PDF

• Product Manual: PDF
